Heat Treat & Abrasion Resistant

Related Products & Services

Farwest invests in an extensive abrasion resistant steel plate inventory.

Farwest either has or can source your requirements for inventoried steel plate manufactured in the As Rolled condition or the Heat Treated condition.

500F Formable

Farwest is proud to carry 500F (Formable) inventory ranging from 3/16″ to 2″ thick in widths primarily in 48″ and 96″ wide.

Yield KSI210 - 230
Tensile KSI230 - 255
Elongation % in 2"14 Min
Brinell Hardness444 - 534
C - Carbon0.3
Mn - Manganese1.15
P - Phosphorus0.015
S - Sulphur0.005
Si - Silicon0.6
Cr - Chromium0.65
Mo - Molybdenum0.4

400F Formable

Farwest is proud to carry 400F (Formable) inventory ranging from 3/16″ to 2″ thick in widths primarily in 48″ and 96″ wide.

Yield KSI160
Tensile KSI170 - 190
Elongation % in 2"15 Min
Brinell Hardness363 - 444
C - Carbon0.17
Mn - Manganese1.5
P - Phosphorus0.015
S - Sulphur0.005
Si - Silicon0.6
Mo - Molybdenum0.4

AR500

Farwest inventories AR500 ranging from 3/16″ to 2″ thick in 48″ and 96″ widths. Farwest can source your other requirements using our network of mills.

Brinell Hardness460 - 544
C - Carbon0.32
Mn - Manganese0.95
P - Phosphorus0.025
S - Sulphur0.005
Si - Silicon0.55
Ni - Nickel1.0
Cr - Chromium0.75
Mo - Molybdenum0.65

AR400

Farwest inventories AR400 in 3/16″ to 2″ thick in 48″ and 96″ widths. Farwest can source your other requirements by using its network of mills.

Brinell Hardness360 - 444
C - Carbon0.21
Mn - Manganese1.55
P - Phosphorus0.025
S - Sulphur0.005
Si - Silicon0.55
Ni - Nickel1.0
Cr - Chromium0.55
Mo - Molybdenum0.4

A514

Farwest is proud to carry ASTM A514 inventory ranging from 3/16″ to 8″ thick in widths primarily in 48″ and 96″ wide.

Yield KSI100
Tensile KSI110 - 130
Elongation % in 2"18 Min
C - Carbon0.12 - 0.21
Mn - Manganese0.70 - 1.0
P - Phosphorus0.035
S - Sulphur0.04
Si - Silicon0.2 - 0.35
V - Vanadium0.03 - 0.08
Cr - Chromium0.4 - 0.65
Mo - Molybdenum0.15 - 0.25
Ti - Titanium0.01 - 0.03

AR180-235 As Rolled

Farwest is proud to carry AR180-235 inventory sourced in the As Rolled condition ranging from 3/16″ to 1″ thick in 48″ and 96″ wide.

Yield KSI70
Tensile KSI115
Elongation % in 8"16 Min
Brinell Hardness180 - 235
C - Carbon0.5
Mn - Manganese1.2 - 2.0
P - Phosphorus0.05
S - Sulphur0.055
Si - Silicon0.10 - 0.35

Physical and chemical properties are provided for a quick reference only. Please refer to the specification publisher for official physical and mechanical properties. ASTM specifications can be found here.
